EDM Blocks for Stamping Electronic Precision SPCC
Product Introduction:
GA Series—Materials for Stamping Lead Frame and Electronic Connector
GA series provides the best solution for high speed stamping SPCC, steel belt, beryllium copper belt and 304 stainless electronic components, etc. This series is widely recommended by PG components manufacturing field because of its high reputation in the lead frame and connector industry.
Conventional sintered cemented carbide often has micro-pores inside, which become the source of cracks that cause damage to the work piece. Filling with inert gas at the sintering temperature and performing HIP treatment can effectively eliminate micro-pores and significantly improve the mechanical properties of the alloy, all GEHM EDM blocks are HIP processed.
Specification:
GA Series EDM Blocks
|
Type |
Dimensions(mm) Tol.(mm） |
Grade | |||
|
L |
W |
H |
|||
|
(+0.6~+2) |
(+0.6~+2) |
(+0.2~+0.4) |
GA10H |
GA20 |
|
|
MA125 |
125 |
112.5 |
1.5-10.5 |
△ |
△ |
|
MA105 |
105 |
105 |
19.5-80.5 |
O |
△ |
|
Type |
Dimensions(mm) Tol.(mm） |
Grade | |||
|
L |
W |
H |
|||
|
（0~+5） |
（0~+5） |
(+0.5~+0.6) |
GA10H |
GA20 |
|
|
MA150 |
150 |
150 |
6-56 |
O |
O |
|
△：Inventory |
Product status |
||||
|
O:Available |
Top and bottom ground, stress released, HIP treated |
||||
|
Inventory quantity may not be sufficient due to shipment, |
|||||
Grade property:
|
Grade |
Co% |
Hardness |
Density |
TRS |
|
GA10H |
6.00 |
90.5±0.5 |
14.85±0.1 |
≥3000 |
Features:
GA10H increases the incompatibility between the carbide mold and the materials, which prevents the material from retaining on the mold. This grade is suitable for stamping soft materials like pure steel, pure copper and SPCC at high speed.
Applications:
●Stamping pure steel
●Stamping pure copper
●Stamping SPCC
Our Certifications:
ISO 9001，ISO 14001，GB/T 24001
Our factory:
Exhibition & Trade show
FAQ:
1. What is your relationship with Xiamen GESAC？
GEHM and GESAC belong to same mother company—XTC group, specialized in different product ranges. GEHM makes carbide sintered blanks, while GESAC produces finished parts.
2. What are your main products?
Our main products includes EDM blocks, wire drawing dies, hobs, many kinds of wear parts, inserts, saw disks, strips etc. We produce many kinds of cemented carbide products.
3. Are your products made of pure virgin materials or recycled materials?
Our products are made of pure virgin materials which can guarantee quality.
4. What is your monthly output of EDM blocks?
We sell around 20 tons EDM blocks monthly.
5. What is the warranty?
We can issue material certificate upon delivery. If there is any discrepancy on quantity/weight, please let us know within 2 weeks after arrival of the goods. If there is any quality discrepancy, please send us the report with 4 weeks. Thanks.
Packaging & Delivery
The products will be packed carefully before shipping to ensure that the product arrives without any damage. Neutral packing box is for each pcs, wooden box is for large qty
Our customers have a wider range of choices for transportation mode, by air, by express, by sea.
